Description
1.USB bus powered 4.0 to 5.25V
2. Self-powered 3.0 to 3.6V, I/0 voltage 1. 8V to VDD
3. Operating ambient temperature: -40°C to 85°C
4. On-chip plus point reset circuit, on-chip voltage regulator: 3. 45V output
5. Compliant with USB specification 2.0 standard; full speed (12Mbps)
6. Supports USB pending status via SUSPEND pin
7. Integrated 194-byte one-time programmable ROM for storing customizable product information
8. 512-byte SMBus data buffer, configurable clock speed device address 7-bit value i.e. CP2112 slave device address
9. Windows, Mac and Linux HID to SMBus library API for rapid application development, open access interface specifications
10. 8 GPI0 configurable as input/output and open drain/push-pull, configurable clock output for external devices 48MHz to 94KHZ, read/write SMBus device switching LED
11. Application areas: portable controller, USB dongle, data logging
