Description
– Compact Size – 1 Module
– Out 1 Contact SPDT
-Adj Under: 75-95% Vn
-Adj Over: 105-125% Vn
– Time range 0,2-10 sec
– De-energise after delay
– Din Rail EN50.022
TECHNICAL SPECIFICATIONS:
POWER SUPPLY:
AC: 3 x 400 Hz: 47-63
Max Consumption: 15VA
OUTPUT RELAY:
Contact: SPDT
Current: 8A
Voltage: 250VAC
Temperature:
Work:-10/+50˚C
Electrical Strength: 4kV
Protection Degree: IP40
Relative Humidity: 95 RH%
Weight: 65g
Dimensions:
98 x 17,5 x 64mm
