OKY3496-4
2V 24V 30V 40V Pulse Width Modulator PWM DC Motor Speed Control Switch Speed Governor
Product Description
1.With Imported 50V 1000uF large capacitor.
2.Power tube using IRF3205 this bull,no worry about your motor not moving.(parameter drain current Id Max: 82A; voltage Vds Max: 75V; open state resistor, Rds (on): 0.013ohm).
3.Terminals use 8500 large current terminals, labeled 300V20A.
4.Potentiometer resistance: B100K.
5.Openings: 8mm.
6.Working power: DC12-V40V.
7.Power control: 12V*8A=96W ,24V*8A=192W,40V*8A=320W.
8.Rated current: 8A.
9.Maximum current: 10A.
10.Speed range: 10%-100%.
11.PWM Frequency: 13KHZ.
12.Product size: approx. 60*55*28mm/2.36*2.16*1.1”.
