Description
| Applicable fluid | (Pneumatic type) Air, Non-corrosive gas |
|---|---|
| Pressure port direction | Rear fitting |
| Pressure port | Rc1/8 |
| Connection type | Connector type(connector type cable: 2m) |
| Pressure type | Standard pressure |
| Rated pressure range | 0 to 1,000kPa |
| Display pressure unit | MPa, kPa, kgf/cm², bar, psi |
| Control output_PNP open collector | PNP open collector |
| Option input/output | Voltage(1-5VDC  ) output |
| Power supply | 12-24VDC ±10%(ripple P-P: max. 10%) |
| Current consumption | Voltage output type: Max. 50mA Current output type: Max. 75mA |
| Protection structure | IP40 |
| Control output_Hysteresis | Min. display interval |
| Control output_Repeat error | ±0.2% F.S. ±Min. display interval |
| Control output_Response time | Selectable 2.5ms, 5ms, 100ms, 500ms, 1000ms |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 30 to 80% RH, storage: 30 to 80% RH |
| Material | Front, Rear case: Polycarbonate, Pressure port: Nickel Plated Brass |
| Weight | Approx. 165g(approx. 80g) |
※In case of using M5 port, use PSO-Z01 (M5 Gender) together.
※In hysteresis output mode, detection difference is variable.
※It is allowed to select one analog output type only.
※The weight includes packaging. The weight in parenthesis is for unit only.
※The unit is sealed structure. It is based on atmospheric pressure 101.3kPa.
※F.S: Rated pressure.
※There may be ±1-digit error in hysteresis by pressure unit calculation error.
※The temperature or humidity mentioned in Environment indicates a non freezing or condensation.
