Cable Type: RG-59/U
-
Nominal Capacitance (pF/ft): 20.5
-
Loss @ 100 MHz: 3.4 dB
-
Center Conductor Material: Copper Clad Steel
-
Shield %: 95% Cu Braid
-
Center Conductor Construction: Solid
-
Center Conductor Diameter: 0.023 in
-
Loss @ 50 Mhz: 2.40 dB
-
VOP: 66 %
-
Loss @ 900 MHz: 11.1 dB
-
Dielectric Insulation: PE
-
Loss @ 1000 MHz: 12.0 dB
-
Nominal Core O.D.: .146
-
Nominal O.D.: 0.242 in
-
Loss @ 400 MHz: 7 dB
RG59/U Coaxial Cable
COAXIAL CABLE 75E-112 SONIC
CONSOLIDATED WIRE’s RG59/U Jan-C-17A black coaxial cable. 75 Ohm, solid center conductor. Polyethylene 95% shield coverage. 66% velocity of propagation sold per foot
Code: RG59/U 300Y
