Description
|
Specifications |
Range |
UT203+ |
|
AC current (A) |
400A |
±(2.5%+5) |
|
DC current (A) |
400A |
±(2.5%+5) |
|
AC voltage (V) |
600V |
±(0.8%+5) |
|
AC voltage frequency(Hz) |
10Hz~60kHz |
±(0.5%+2) |
|
DC voltage (A) |
600V |
±(0.5%+2) |
|
Resistance (Ω) |
40MΩ |
±(0.8%+2) |
|
Capacitance (F) |
40mF |
±(4%+5) |
|
Frequency (Hz) |
10Hz~10MHz |
±(0.1%+4) |
|
Features |
||
|
Display count |
4000 |
|
|
Auto range |
√ |
|
|
Jaw opening |
28mm |
|
|
True RMS |
√ |
|
|
NCV |
√ |
|
|
Continuity test |
√ |
|
|
Diode |
√ |
|
|
MAX/MIN |
√ |
|
|
Relative mode |
√ |
|
|
Zero mode |
√ |
|
|
Data hold |
√ |
|
|
Low battery indication |
√ |
|
|
Auto power off |
√ |
|
|
General Characterisitics |
||
|
Power |
1.5V battery (R03) x 2 |
|
|
Display |
37mm x 25mm |
|
|
Product color |
Red and grey |
|
|
Product net weight |
235g |
|
|
Product size |
215mm x 63mm x 36mm |
