Input voltage: DC 8-35V
Input current: 5.5A
Output voltage: 5.2V
Output current: 8A in total, adaptive current, 2A for single port charging of mobile phone.
Dynamic response speed: 300us (load flow changes by 5%)
Conversion efficiency: 95% (measured from 12V to 5.2V3.5A, the efficiency is related to the pressure difference and load size.)
Load adjustment rate: 0.2-0.3% (measured by 10% – 50% load 12V input)
Ripple&noise: 120mVP-P (measured from 12V to 5.2V3A at 20MHz bandwidth)
Switching frequency: 100KHz
No load current: 18mA (measured at 5V on 12V vehicle)
Wiring mode: IN input OUT input terminal DC base
Fixing method: M3 * 1 M2 * 2
Net weight: about 36g
Supported devices:
Mobile phone, digital camera, tablet computer, navigator, tachograph and other devices that need USB power supply. It can charge 4 mobile phones at the same time, with a total current of 8A.
Multiple input and output modes, supporting terminal input, DC seat input, output supporting 4 * USB output, terminal output 5V.
External dimensions:
54 (L) * 39 (W) * 21 (H) mm (including USB port)
Pin mode:
VIN+input positive pole, GND common ground, OUT+output positive pole
matters needing attention:
(1) Do not use under overvoltage or overload, otherwise the battery and power supply will be damaged.
(2) The module can only reduce voltage but not increase voltage, and cannot supply power to electrical equipment higher than the input voltage.
(3) Ventilation and heat dissipation shall be paid attention to when working with large current and power under full load for a long time to prolong the service life of the power supply.
(4) Do not work at full load for a long time. Please leave 20% margin when working continuously. Pay attention to ventilation and heat dissipation
